• Hot water safety lock
  • No spill sealed system
  • #304 stainless cold reservoir
  • #304 stainless hot tank
  • #304 stainless waterways
  • Leak prevention
  • One piece blow molded polyethylene cabinet
  • Two year limited warranty
  • Free standing internal structure
  • Carry handle


A robust bottle water dispenser with a classic design. The Aspen is the perfect water cooler for home and office delivery. Featuring Stainless tanks and a one-piece blow molded cabinet. The Aspen is built to perform and is backed by our company known for innovation, quality and support.


Power rating Single phase
110-115VAC 60Hz
Standard current Hot & Cold: 4.5-5.1A
Cold 85W
Hot 400W
Cold Compressor Single phase motor
Refrigerant R134a
Temp range 5-10°C (41-50°F)
Capacity 3.47L (0.9 gal)
Hot Heater Band heater
Temp range 74-92°C (165.2-197.6°F )
Temp control 82-89°C (179.6-192.2°F )
Capacity (External Heater) 1.47L (0.3 gal)
Refrigerant charge 34g (1.2 oz)
Product weight HOT & COLD:12kg (26.5 lb)
Product boxed weight HOT & COLD:13kg (28.6 lb)
Product dimensions 320(W) X320(D) X980(H)mm
12.6"(W) X 12.6"(D) X 38.6"(H)
Product boxed dimensions 325(W) X 335(D) X 1000(H)mm
12.8"(W) X 13.2 "(D) X 39.4"(H)
Loading quantity 20' Container: 238 Units
40' Container: 504 Units
IEC protection class Class 1
Certifications C-CSA-US, NSF372
Warranty Two Year


WARNING: This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.


  •  Aspen  Brochure       →  Download

Specifications Data

  • 110V Aspen Bottled Water Dispenser (Hot & Cold)         →  Download
  • 110V Aspen Bottled Water Dispenser (Cook & Cold)       → Download


  • Crystal Mountain Two Year Limited Warranty               →   Download


  • High-Resolution Photos                                                →   Download
